Steps for correctly adjusting the support roller in an energy efficient rotary kiln

The rotary kiln is widely used in the metallurgy, chemical industry, construction and other industries.

1. Adjust the rotary kiln support roller simple memory method to face the rotary kiln body on the side of the reducer, the left top support on the top wire (kiln body) to the left string, and the right top support roller top wire (kiln body) to the right. Standing on the other side, the left top support wheel top wire (kiln body) is skewed to the right, and the right top support wheel top wire (kiln body) is skewed to the left.

2. According to the gap between the support roller and the two ends of the base, the base of the two ends of the support roller is used as the coordinate. If the running position of the support roller is lower, the force of the support roller on the rotary kiln body is upward. If the operation position of the tractor is on the upper side, the support is provided. The force of the wheel on the kiln is down. Understand these principles, combine the string on the kiln body or the next string to adjust the angle of the roller, increase or decrease the force of the tug to the rotary kiln, and achieve the smooth operation of the rotary kiln.

3. Adjusting the precautions of the supporting roller. Due to the complicated state of the rotating kiln supporting roller, the adjustment of the position and angle of the tug cannot be quantified. It can only be analyzed and determined according to the actual situation, and after several adjustments, the purpose can be achieved, so each time the tug is adjusted Careful observation should be made to determine the purpose of adjustment and adjust the number of roller sets. Do the adjustment position of the roller and the number of exits of the top wire. Adjust the tug as fine as possible and make a record. After adjustment, observe for eight hours. If the adjustment is not achieved, For the purpose of making a new round of adjustments
